2-7 Soft Carrying Case Instrument Overview
To install the Site Master into the soft carrying case:
1. Fully close the front panel of the soft carrying case and place the
case face down on a stable surface.
2. Open the zipper closest to the D-rings on the sides and bottom of
the soft case to install Site Master.
3. Insert the instrument face down into the case.
4. Close the zipper to secure the Site Master.
5. Turn the soft case over and open the front panel of the case to use
the Site Master.
6. A tethered stylus pen to use with the touchscreen is stored inside
the soft case on the top panel, near the RF ports. Store the stylus
pen in the sleeve when not in use. Replacement stylus pens with
the coiled tether cord are available from Anritsu. Refer to the
Site Master data sheet (11410-00616).
Note
The grey nylon pull tab at the rear bottom of the case opens
the tilt bail support panel. Adjust the open tilt angle with the
hook-and-loop fastener strap. This support panel also contains
two storage pockets that provide convenient and secure
storage for calibration components and adapters.
