IDA8 Global-Net User Manual114
© 2020, ATEÏS. All rights reserved.
Show the status of zone:
Priority of the zone is lower than other sources.
Priority of the zone is higher than other sources.
The zone only desired for paging is not using by other
sources.
Fault LED:
To display fault status of system. The following table list the states of fault,
There are faults in audio processor.
Lost communication with audio processor.
EVAC LED:
System is under evacuation paging.
PSC does not do a "Plug-in" in Ateis Studio before using.
"Remote Plug-in" makes audio processor to recognize the peripheral devices.
Power LED:
This LED light up when the PSC is powered on.
Event Select Key:
These buttons are used to select keys, each key may link to an event for triggering actions like
paging or adjust the value of parameters.
Talk Indicator:
This LED light up if PSC is allowed to paging, on the other word, the paging request has been
acknowledged.
Sometime after paging request is granted, zones under paging still can be occupied by other
sources. In such a case, the talk LED still light up, but you can check busy LED to know the
situation.
Talk Key:
Push this key to request paging.
Hold LED:
These LEDs Indicate which keys are selected.
All/Release Button:
This button is used for selecting or deselecting all keys.
All/Release LED:
This indicator lights up if all keys are selected.
3.2.1.7.2 Configuration
The example here is the IDA8 system, the configuration is the same for ESC, LAPG2T and other
Ateis Audio Processor.
Create PSC Object
