Ateis IDA8 Series User Manual

IDA8 Global-Net User Manual524
© 2020, ATEÏS. All rights reserved.
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 200Hz ~ 20kHz
Music Input
Input Impedance:
10kOhm
Maximum level:
12dBu
THD:
@ 1kHz < 0.1%
Bandwidth:
@ -3dB = 20Hz ~ 20kHz
Mechanical
Dimensions (W x H x D):
483 mm x 220 mm x 68 mm
Weight:
3.9Kg
Color:
RAL7035
Maximum Cable Length:
100m (control and power on the same cable)
900m (when power line connects to junction box)
Operating temperature:
0ºC ~ 55ºC
9.5.14 PCP
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~26V, Typical 24V
150mA
-
Handset Microphone Output
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 0.1%
Bandwidth:
@ -3dB = 50Hz ~ 20kHz
Front Panel Loudspeaker
Impedance:
8Ohm
Maximum Power:
@ 1kHz = 1W
THD:
@ 1kHz < 1%
Bandwidth:
@ -3dB = 200Hz ~ 20kHz
Music Input
Input Impedance:
10kOhm
Maximum level:
12dBu
THD:
@ 1kHz < 0.1%
Bandwidth:
@ -3dB = 20Hz ~ 20kHz
Mechanical
Dimensions (W x H x D):
346 mm x 220 mm x 128 mm
Weight:
3Kg
Color:
RAL7035
Maximum Cable Length:
100m (control and power on the same cable)
900m (when power line connects to junction box)
Operating temperature:
0ºC ~ 55ºC
9.5.15 PSC
Electrical
Item
Voltage
Current Consumption
Comment
DC Input
18V~26V, Typical 24V
150mA
-
Microphone
Microphone level:
6dBu
Output Impedance:
100Ohm
THD:
@ 1kHz < 0.1%
