IDA8 Global-Net User Manual382
© 2020, ATEÏS. All rights reserved.
Control Window
Element Description
Bypass/Mute: Disable/mute the audio channel.
RTO: The input channel 'Routed To Output(s)'.
Overload: Light up if the signal of input channel is bigger
than Overload Thd.
Volume: The VU-Meter shows the channel of RMS level.
Signal: Light up if an audio signal presents above -30 dB
from the chosen 'Sensitivity'.
Level: The signal output level of channel.
Overload Thd.: A threshold value to determine the signal of
a channel is overloaded or not.
6.10 Inverter
Allow to change the signal phase of 90 degrees.
Control Window
Element Description
Mute: Mute the inverter module.
Invert: Activate the inverter.
