Ateis IDA8 Series User Manual

System Configuration 291
© 2020, ATEÏS. All rights reserved.
STX
Data Section
STX
T
EXT
CR
Answer is always ACK CR or None, depend on communication protocol settings.
5.5.1.5.1.5 Control Command (IDA8)
1. Change Preset
command string = Mvvvv
STX
Data Section
STX
Mvvvv
EXT
CS
CR
STX
Data Section
STX
Mvvvv
EXT
CR
vvvv = Master preset number
2. Load Sub-Preset
command string = Svvvv
STX
Data Section
STX
Svvvv
EXT
CS
CR
STX
Data Section
STX
Svvvv
EXT
CR
vvvv = Sub-Preset number
3. Reply Read Parameter Command
Command string =Rnnnnvvvv
STX
Data Section
STX
Rnnnnvvv
STX
Data Section
STX
Rnnnnvvv
DB element
nnnn = function name (fixed 4 length)
vvvv = sign + integer(fixed 2 length) + dot + decimal(fixed 1 length)
Other element
Answer is always Rnnnnvvvv (Reply Read Para. Com.)
nnnn = function name (fixed 4 length)
vvvv = value (unfixed)
4. Reply Machine System Value
Command string =Pnnnnvvvv
STX
Data Section
STX
Pnnnnvvv
