Ateis IDA8 Series User Manual

Technical Data 513
© 2020, ATEÏS. All rights reserved.
Audio Characteristics
Frequency response:
±3dB@50Hz ~ 20KHz
Distortion at nominal power:
<0.1% (@ 1 kHz) @ -10dB of rated output power
SNR (Signal-to-noise ratio):
> 90 dB
Inputs/Outputs:
Power output: 100 V
Main line input: 770 mV
Input impedance: 20K Ohm
Loudspeakers Outputs
DPA4125:
Rated load resistance = 80 ohm (100 V)
Rated load capacitance = 62,5 nF (100 V)
Rated output power = 125 W (cont. at 40°C)
Two channels bridged = 250 W (cont. at 40°C)
DPA4125:
Rated load resistance = 40 ohm (100 V)
Rated load capacitance = 120 nF (100 V)
Rated output power = 250 W (cont. at 40°C)
Two channels bridged = 500 W (cont. at 40°C)
Frequency response:
40 Hz to 20 kHz (-3 dB)
S/N:
>90 dB (no pilot tone)
Crosstalk:
<70 dB at nominal load for 1 kHz
Distortion:
<0,1% (@ 1 kHz) @ -10dB of rated output power
Environmental
Operating temperature:
-5ºC ~ 55ºC (23 ºF ~ 131 ºF)
Storage temperature:
-40 ºC ~ 70 ºC (-40 ºF ~ 158 ºF)
Relative humidity:
15% to 90%.
Air pressure:
600 to 1100 hPa
Mechanical
Dimensions(W x H x D):
DPA4125/DPA4250: 88.5 x 483 x 370 mm
Weight:
DPA4125 = 14 Kg (31 lb)
DPA4250 = 18 Kg (40 lb)
Colour:
RAL7016
9.4 Battery Charger
9.4.1 SONAES 6/40A
Network Input
Single-phase voltage: 195 V to 264 V
Frequency: 47 to 63 Hz
Class I
Neutral and earthing systems: TT, TN, IT
Maximum primary current @ 195 V: 1 A
Two pole circuit breaker (D curve) to be provided upstream
Output
Rated voltage: 24 V
Rated output current for battery charge : 6A
Floating voltage set at half-load and at 25 °C: 27. 2 V ±0.5 %
2 ‘amplifiers’ outputs with a current of 20A maximum per output
