6 DSP Components
6.1 Delay (Advanced & Basic)
Used to delay the audio signal input to the component. The delayed component records the audio
into a internal buffer and then plays the stored audio based on parameters set by users. There are
two ways to adjust the delay time for a channel. First, adjust the element delay time, then adjust the
Element Temp and Distance. Element Type can be switched between two modes.
Control Window
Maximum Value
Precision Value
Distance
Type
Maximum Value
Type
Maximum Value
Type
Maximum Value
5ms
5000 µs
5ms
5 µs
5ms
1.62 m
50ms
50000 µs
50ms
20 µs
50ms
16.25 m
100ms
100000 µs
100ms
20 µs
100ms
32.5 m
200ms
200000 µs
200ms
20 µs
200ms
65 m
500ms
500000 µs
500ms
20 µs
500ms
162.5 m
1000ms
1000000 µs
1000ms
20 µs
1000ms
325 m
2000ms
2000000 µs
2000ms
20 µs
2000ms
650 m
Type: Choose between adjusting with Time or with Distance and temperature.
Mute/Mute all: Mute (all) the output channel(s).
Bypass/Bypass all: Bypass the audio signal of (all) the channel(s). Note: This will disable the
Delay function.
Delay Time: Specify how much time will be delayed for the audio signal of a channel.
Temp: Specify the temperature to compute the delay time of a channel.
