Ateis IDA8 Series User Manual

IDA8 Global-Net User Manual518
© 2020, ATEÏS. All rights reserved.
Warning:
o Replacing the original battery with a battery of incorrect type may result in an explosion
hazard.
o Used batteries must be disposed of in compliance with recycling requirements.
Fuse Protections:
F1 mother board (mains):
rating- type - size - breaking capacity
6.3 A T for 24V version
8A T for 48V version
5x20
1500 A breaking capacity
F8 mother board
rating - type - size
12.5A
5x 20
F1 to F6 main outputs board (6 outputs):
rating - type - size
32 A gG
10 x 38
Faux1 to Faux3 auxiliary outputs board (3
outputs):
rating - type - size
5A F
5x20
External battery fuse (not fitted with PSE):
rating - type
[Ibmax (mains not present)] A
gG type
9.5 Console
9.5.1 DialPad
Mechanical
Dimensions(L x W x H):
255mm x 108mm x 66mm
Telephone Keypad:
Touch key (0~9 , #, * )
Support resembles telephone keypad
Panel Display:
128*32 Pixels
Monochrome (White)
Buzzer:
Sound pressure level >85dBA@10cm
Status LED:
Blue
ø 3mm
Display the status of button
RS485 Protocol:
RJ45 @Maximum Distance 500M(between system unit and
DialPad)
24 VDC@ 30 mA maximum
24 VDC@ 20 mA sleeping mode
Battery Holder:
4”AAA”
6 VDC@ 100mA maximum
6 VDC@ 70mA sleeping mode
Weight:
0.5kg
Colour:
RAL7016
Environmental
Operating temperature:
0ºC ~ 40ºC
9.5.2 Wireless Transceiver
Mechanical
Dimensions(L x W x H):
100mm x 67mm x 30mm
POWER LED:
Green
ø 3mm
Display for Power supply
