System Products 153
© 2020, ATEÏS. All rights reserved.
Version: Display the firmware version of URC-200.
S. B.: This page is comprised of the two settings:
Saver Time (min.): The waiting time that the menu go back to root page.
Black Time (min.): The waiting time that the URC-200 enters sleep mode.
Reset: If you modify the settings as the protected mode, please enable this function to save value.
Return: Enable this function to go back to root menu.
3.2.5.4 Troubleshooting
This chapter will help you to diagnose and solve the common problems with detailed explanation,
any other information should be listed here as reference as well.
Hardware maintenance:
1. Be sure to keep the case clean and away from any heat source.
2. The operating temperature is 0°C ~ 40°C.
3. Keep it clean, especially air filters and ventilation paths (If the device has a fan).
4. Avoid vibrations and shocks.
3.2.6 URGP32I
The URGP 32I is an extension unit for the IDA8-System, LAPG2T and ECS. The URGP32I provides
those systems with 32 additional alarm inputs. Each input is monitored and can be programmed to
trigger a digital audio message into a specific zone or group of zones. The URGP is linked to the
System units through a RS232 /RS485 monitored serial link.
3.2.6.1 Front Panel
Evacuation LED:
Light up in red when the Evacuation input is active or blinks while boot. The following table lists
the states of the Evac LED:
One of the Evacuation inputs is active.
Blinks 5 times after powered on.
Fault LED:
