Ateis IDA8 Series User Manual

IDA8 Global-Net User Manual290
© 2020, ATEÏS. All rights reserved.
o ACK 0x06 DLE 0x10 NACK 0x10
o The answers are not inserted inside STX…ETX LRC CR frame.
5.5.1.5.1.1 Increase/Decrease Command
Command string = I/D nnnn vvvv
STX
Data Section
STX
I/D nnnn vvvv
EXT
CS
CR
STX
Data Section
STX
I/D nnnn vvvv
EXT
CR
nnnn = function name (fixed 4 length)
vvvv = value (unfixed)
For example: Room1 volume, value = 3 dB
'STX' + IR0013 + 'EXT' + 'CS' + 'CR '
'STX' + IR0013 + 'EXT' + 'CR '
5.5.1.5.1.2 Write Parameter Command
Command string = W nnnn vvvv
STX
Data Section
STX
W nnnn vvvv
EXT
CS
CR
STX
Data Section
STX
W nnnn vvvv
EXT
CR
nnnn = function name (fixed 4 length)
vvvv = value (unfixed)
For example: cd1, value = 10 dB
'STX' + WCD110 + 'EXT' + 'CS' + 'CR '
'STX' + WCD110 + 'EXT' + 'CR '
5.5.1.5.1.3 Read Parameter Command
Command string =Rnnnn
STX
Data Section
STX
Rnnnn
EXT
CS
CR
STX
Data Section
STX
Rnnnn
EXT
CR
nnnn = function name (fixed 4 length)
Answer is always Rnnnnvvvv (Reply Read Para. Com.)
5.5.1.5.1.4 Connect Test Command
Command string = T
STX
Data Section
STX
T
EXT
CS
CR
