System Products 53
© 2020, ATEÏS. All rights reserved.
PMIP-D
PPM-IT5
VNB
Local Ateis Net Connectors:
Optional card to build a local dedicated IDA8C-IDA8S network.
Global Ateis Net Connectors:
Optional card to build a global dedicated IDA8C network.
Configurable Audio I/Os:
Two configurable 0dB audio I/O port A and B. Each port is available to assemble an audio card.
There are 4 channels on each audio I/O card.
BNC Connector:
BNC Connector for AES/EBU Card.
Telephone Line Input and Connector:
A connector for a telephone signal coming from telephone company and external telephone
connection (optional).
Interface: a/b (analog), support 74 countries.
Dialing modes: vocal
Connection: PABX
Supported Standards: FSK and DTMF
Interface: RJ11
Technology: Noise Suppression, Line Echo Cancellation, Voice Enhance
Bypass Mode Outputs:
This port is used to share the bypass mode microphone signals through the IDA8C-IDA8S
network(only needed when using fiber optic network).
Contact Outputs:
8 logic outputs channels are used to close/open a circuit for an external device. This contact is
normally open.
Evacuation Inputs:
9 evacuation contact inputs that allow the monitoring of external contact. They also can be used
in UGA mode, trigger by a voltage polarization change.
24V DC Output:
This connector supplies a 24VDC source.
24V DC Input:
Main 24VDC power supply connector.
AC Power Socket:
Main 110~240 V 1.2A, 47~63Hz AC power input with fuse. If 24V DC and AC power inputs are
connected at the same time, IDA8C will use AC power, and switch to DC power if there is no
AC power input.
Fuse Rating: 3.15A
