Atmel AVR XMEGA AU series User Manual

103
8331B–AVR–03/12
Atmel AVR XMEGA AU
7.11.5 COMP2 – DFLL Compare register Byte 2
• Bit 7:0 – COMP2[15:8]: Compare Register Byte 2
These bits hold byte 2 of the 16-bit compare register.
Bit 76543210
+0x06 COMP[15:8] COMP2
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
Table 7-11. Nominal DFLL32M COMP values for different output frequencies.
Oscillator Frequency (MHz) COMP Value (Clk
RCnCREF
= 1.024kHz)
30.0 0x7270
32.0 0x7A12
34.0 0x81B3
36.0 0x8954
38.0 0x90F5
40.0 0x9896
42.0 0xA037
44.0 0xA7D8
46.0 0xAF79
48.0 0xB71B
50.0 0xBEBC
52.0 0xC65D
54.0 0xCDFE
