Atmel AVR XMEGA AU series User Manual

407
8331B–AVR–03/12
Atmel AVR XMEGA AU
30.10 Register Summary
30.11 Interrupt vector Summary
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 AC0CTRL INTMODE[1:0] INTLVL[1:0] HSMODE HYSMODE[1:0] ENABLE 401
+0x01 AC1CTRL INTMODE[1:0] INTLVL[1:0] HSMODE HYSMODE[1:0] ENABLE 401
+0x02 AC0MUXCTRL – – MUXPOS[2:0] MUXNEG[2:0] 402
+0x03 AC1MUXCTRL – – MUXPOS[2:0] MUXNEG[2:0] 402
+0x04 CTRLA – – – – – – AC1OUT ACOOUT 403
+0x05 CTRLB – – SCALEFAC5:0] 403
+0x06 WINCTRL – – – WEN WINTMODE[1:0] WINTLVL[1:0] 403
+0x07 STATUS WSTATE[1:0] AC1STATE AC0STATE – WIF AC1IF AC0IF 404
+0x08 CURRCTRL CURRENT CURRMODE – – – – AC1CURR AC0CURR 405
+0x09 CURRCALIB – – – – CALIB[3:0] 405
Table 30-7. Analog comparator interrupt vectors.
Offset Source Interrupt Description
0x00 COMP0_vect Analog comparator 0 interrupt vector
0x02 COMP1_vect Analog comparator 1 interrupt vector
0x04 WINDOW_vect Analog comparator window interrupt vector
