Atmel AVR XMEGA AU
36.5 LPC 2- Port ALE12 CS
Figure 36-17. Write, ALE1
Figure 36-18. Write, ALE1 + ALE2
A[7:0]
ALE1
Write, ALE1
ALE2
D[7:0]/A[7:0]/A[15:8]
D[7:0]
Clk
PER2
RE
WE
CS
D[7:0]A[7:0]
ALE1
Write, ALE1 + ALE2
A[15:8]
ALE2
D[7:0]/A[7:0]/A[15:8]
Clk
PER2
RE
WE
CS
