Atmel AVR XMEGA AU series User Manual

319
8331B–AVR–03/12
Atmel AVR XMEGA AU
• Bit 3:0 – EVSEL [3:0]: Event Channel Selection
These bits select the event channel source for the IRCOM receiver according to Table 24-1 on
page 319. If event input is selected for the IRCOM receiver, the input from the USART’s RX pin
is automatically disabled.
24.4 Register Summary
Table 24-1. Event channel selection.
EVSEL[3:0] Group Configuration Event Source
0000 None
0001 (Reserved)
0010 (Reserved)
0011 (Reserved)
0100 (Reserved)
0101 (Reserved)
0110 (Reserved)
0111 (Reserved)
1nnn CHn
Event system channel n; n = {0, …,7}
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 CTRL – – – – EVSEL[3:0] 318
+0x01 TXPLCTRL TXPLCTRL[7:0] 318
+0x02 RXPLCTRL RXPLCTRL[7:0] 318
