3.14 Register Descriptions
3.14.1 CCP – Configuration Change Protection register
• Bit 7:0 – CCP[7:0]: Configuration Change Protection
The CCP register must be written with the correct signature to enable change of the protected
I/O register or execution of the protected instruction for a maximum period of four CPU instruc-
tion cycles. All interrupts are ignored during these cycles. After these cycles, interrupts will
automatically be handled again by the CPU, and any pending interrupts will be executed accord-
ing to their level and priority. When the protected I/O register signature is written, CCP[0] will
read as one as long as the protected feature is enabled. Similarly when the protected SPM/LPM
signature is written, CCP[1] will read as one as long as the protected feature is enabled.
CCP[7:2] will always read as zero. Table 3-1 on page 15 shows the signature for the various
modes.
3.14.2 RAMPD – Extended Direct Addressing register
This register is concatenated with the operand for direct addressing (LDS/STS) of the whole
data memory space on devices with more than 64KB of data memory. This register is not avail-
able if the data memory, including external memory, is less than 64KB.
• Bit 7:0 – RAMPD[7:0]: Extended Direct Addressing bits
These bits hold the MSB of the 24-bit address created by RAMPD and the 16-bit operand. Only
the number of bits required to address the available data memory is implemented for each
device. Unused bits will always read as zero.
3.14.3 RAMPX – Extended X-Pointer register
This register is concatenated with the X-register for indirect addressing (LD/LDD/ST/STD) of the
whole data memory space on devices with more than 64KB of data memory. This register is not
available if the data memory, including external memory, is less than 64KB.
Bit 76543210
+0x04 CCP[7:0] CCP
Read/WriteWWWWWWR/WR/W
Initial Value 00000000
Table 3-1. Modes of CPU change protection.
Signature Group Configuration Description
0x9D SPM Protected SPM/LPM
0xD8 IOREG Protected IO register
Bit 76543210
+0x08 RAMPD[7:0] RAMPD
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
