3.15 Register Summary
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 Reserved – – – – – – – –
+0x01 Reserved – – – – – – – –
+0x02 Reserved
– – – – – – – –
+0x03 Reserved
– – – – – – – –
+0x04 CCP CCP[7:0] 15
+0x05 Reserved – – – – – – – –
+0x06 Reserved – – – – – – – –
+0x07 Reserved – – – – – – – –
+0x08 RAMPD RAMPD[7:0] 15
+0x09 RAMPX RAMPX[7:0] 15
+0x0A RAMPY RAMPY[7:0] 16
+0x0B RAMPZ RAMPZ[7:0] 16
+0x0C EIND EIND[7:0] 16
+0x0D SPL SPL[7:0] 17
+0x0E SPH SPH[7:0] 17
+0x0F SREG I T H S V N Z C 18
