13.16 Register Summary – Ports
13.17 Register Summary – Port Configuration
13.18 Register Summary – Virtual Ports
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 DIR DIR[7:0] 153
+0x01 DIRSET DIRSET[7:0] 153
+0x02 DIRCLR DIRCLR[7:0] 153
+0x03 DIRTGL DIRTGL[7:0] 153
+0x04 OUT OUT[7:0] 154
+0x05 OUTSET OUTSET[7:0] 154
+0x06 OUTCLR OUTCLR[7:0] 154
+0x07 OUTTGL OUTTGL[7:0] 155
+0x08 IN IN[7:0] 155
+0x09 INTCTRL – – – – INT1LVL[1:0] INT0LVL[1:0] 155
+0x0A INT0MASK INT0MSK[7:0] 155
+0x0B INT1MASK INT1MSK[7:0] 156
+0x0C INTFLAGS – – – – – – INT1IF INT0IF 156
+0x0D Reserved – – – – – – – –
+0x0E REMAP
– – SPI USART0 TC0D TC0C TC0B TC0A 156
+0x0F Reserved
– – – – – – – –
+0x10 PIN0CTRL SRLEN INVEN OPC[2:0] ISC[2:0] 157
+0x11 PIN1CTRL SRLEN INVEN OPC[2:0] ISC[2:0] 157
+0x12 PIN2CTRL SRLEN INVEN OPC[2:0] ISC[2:0] 157
+0x13 PIN3CTRL SRLEN INVEN OPC[2:0] ISC[2:0] 157
+0x14 PIN4CTRL SRLEN INVEN OPC[2:0] ISC[2:0] 157
+0x15 PIN5CTRL SRLEN INVEN OPC[2:0] ISC[2:0] 157
+0x16 PIN6CTRL SRLEN INVEN OPC[2:0] ISC[2:0] 157
+0x17 PIN7CTRL SRLEN INVEN OPC[2:0] ISC[2:0] 157
+0x18 Reserved – – – – – – – –
+0x19 Reserved – – – – – – – –
+0x1A Reserved – – – – – – – –
+0x1B Reserved – – – – – – – –
+0x1C Reserved – – – – – – – –
+0x1D Reserved – – – – – – – –
+0x1E Reserved – – – – – – – –
+0x1F Reserved – – – – – – – –
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 MPCMASK MPCMASK[7:0] 159
+0x01 Reserved – – – – – – – –
+0x02 VPCTRLA VP1MAP[3:0] VP0MAP[3:0] 159
+0x03 VPCTRLB VP3MAP[3:0] VP2MAP[3:0] 159
+0x04 CLKEVOUT CLKEVPIN RTCOUT EVOUT[1:0] CLKOUTSEL CLKOUT[1:0] 160
+0x05 EBIOUT
– – – – EBIADROUT[1:0] EBICSOUT[1:0] 161
+0x06 EVCTRL – – – – – EVCTRL[2:0] 162
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 DIR DIR[7:0] 164
+0x01 OUT OUT[7:0] 164
+0x02 IN IN[7:0] 164
+0x03 INTFLAGS – – – – – – INT1IF INT0IF 165
