Atmel AVR XMEGA AU series User Manual

327
8331B–AVR–03/12
Atmel AVR XMEGA AU
25.6 Register Summary - AES
25.7 Interrupt vector Summary - AES
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 CTRL START AUTO RESET DECRYPT –XOR – –324
+0x01 STATUS ERROR – – – – – –SRIF325
+0x02 STATE STATE[7:0] 325
+0x03 KEY KEY[7:0] 326
+0x04 INTCTRL – – – – – – INTLVL[1:0] 326
+0x05 Reserved – – – – – – – –
+0x06 Reserved – – – – – – – –
+0x07 Reserved – – – – – – – –
Table 25-2. AES interrupt vector and its offset word address.
Offset Source Interrupt Description
0x00 AES_vect AES interrupt vector
