12
8331B–AVR–03/12
Atmel AVR XMEGA AU
Figure 3-5. The X-, Y- and Z-registers.
The lowest register address holds the least-significant byte (LSB), and the highest register
address holds the most-significant byte (MSB). In the different addressing modes, these address
registers function as fixed displacement, automatic increment, and automatic decrement (see
the instruction set reference for details).
3.10 RAMP and Extended Indirect Registers
In order to access program memory or data memory above 64KB, the address pointer must be
larger than 16 bits. This is done by concatenating one register to one of the X-, Y-, or Z-registers.
This register then holds the most-significant byte (MSB) in a 24-bit address or address pointer.
These registers are available only on devices with external bus interface and/or more than 64KB
of program or data memory space. For these devices, only the number of bits required to
address the whole program and data memory space in the device is implemented in the
registers.
3.10.1 RAMPX, RAMPY and RAMPZ Registers
The RAMPX, RAMPY and RAMPZ registers are concatenated with the X-, Y-, and Z-registers,
respectively, to enable indirect addressing of the whole data memory space above 64KB and up
to 16MB.
Figure 3-6. The combined RAMPX + X, RAMPY + Y and RAMPZ + Z registers.
When reading (ELPM) and writing (SPM) program memory locations above the first 128KB of
the program memory, RAMPZ is concatenated with the Z-register to form the 24-bit address.
LPM is not affected by the RAMPZ setting.
Bit (individually) 7 R27 07 R26 0
X-register
XH XL
Bit (X-register) 15 8 7 0
Bit (individually) 7 R29 07 R28 0
Y-register
YH YL
Bit (Y-register) 15 8 7 0
Bit (individually) 7 R31 07 R30 0
Z-register
ZH ZL
Bit (Z-register) 15 8 7 0
Bit (Individually) 7 0 7 0 7 0
RAMPX XH XL
Bit (X-pointer) 23 16 15 8 7 0
Bit (Individually) 7 0 7 0 7 0
RAMPY YH YL
Bit (Y-pointer) 23 16 15 8 7 0
Bit (Individually) 7 0 7 0 7 0
RAMPZ ZH ZL
Bit (Z-pointer) 23 16 15 8 7 0
