Atmel AVR XMEGA AU series User Manual

52
8331B–AVR–03/12
Atmel AVR XMEGA AU
4.23 Register Summary - Production Signature Row
Address Auto Load Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 YES RCOSC2M RCOSC2M[7:0] 38
+0x01 YES RCOSC2MA RCOSC2MA[7:0] 38
+0x02 YES RCOSC32K RCOSC32K[7:0] 38
+0x03 YES RCOSC32M RCOSC32M[7:0] 38
+0x04 YES RCOSC32MA RCOSC32MA[7:0] 38
+0x05 Reserved – – – – – – – –
+0x06 Reserved – – – – – – – –
+0x07 Reserved – – – – – – – –
+0x08 NO LOTNUM0 LOTNUM0[7:0] 38
+0x09 NO LOTNUM1 LOTNUM1[7:0] 39
+0x0A NO LOTNUM2 LOTNUM2[7:0] 39
+0x0B NO LOTNUM3 LOTNUM3[7:0] 39
+0x0C NO LOTNUM4 LOTNUM4[7:0] 40
+0x0D NO LOTNUM5 LOTNUM5[7:0] 40
+0x0E Reserved – – – – – – – –
+0x0F Reserved – – – – – – – –
+0x10 NO WAFNUM WAFNUM[7:0] 38
+0x11 Reserved
– – – – – – – –
+0x12 NO COORDX0 COORDX0[7:0] 40
+0x13 NO COORDX1 COORDX1[7:0] 41
+0x14 NO COORDY0 COORDY0[7:0] 41
+0x15 NO COORDY1 COORDY1[7:0] 41
+0x16 Reserved
– – – – – – – –
+0x17 Reserved – – – – – – – –
+0x18 Reserved – – – – – – – –
+0x19 Reserved – – – – – – – –
+0x1A USBCAL0 USBCAL0[7:0] 41
+0x1B USBCAL1 USBCAL1[7:0] 42
+0x1C RCOSC48M RCOSC48M[7:0] 42
+0x1D Reserved – – – – – – – –
+0x0E Reserved – – – – – – – –
+0x1E Reserved – – – – – – – –
+0x20 NO ADCACAL0 ADCACAL0[7:0] 42
+0x21 NO ADCACAL1 ADCACAL1{7:0] 42
+0x22 Reserved – – – – – – – –
+0x23 Reserved – – – – – – – –
+0x24 NO ADCBCAL0 ADCBCAL0[7:0] 43
+0x25 NO ADCBCAL1 ADCBCAL1[7:0] 43
+0x26 Reserved – – – – – – – –
+0x27 Reserved – – – – – – – –
+0x28 Reserved – – – – – – – –
+0x29 Reserved
– – – – – – – –
+0x2A Reserved
– – – – – – – –
+0x2B Reserved – – – – – – – –
+0x2C Reserved
– – – – – – – –
+0x2D Reserved
– – – – – – – –
+0x2E NO TEMPSENSE0 TEMPSENSE0[7:0] 43
+0x2F NO TEMPSENSE1
– – – – TEMPSENSE1[11:8] 44
+0x30 NO DACA0OFFCAL DACA0OFFCAL[7:0] 44
+0x31 NO DACA0GAINCAL DACA0GAINCAL[7:0] 44
+0x32 NO DACB0OFFCAL DACB0OFFCAL[7:0] 44
+0x33 NO DACB0GAINCAL DACB0GAINCAL[7:0] 45
+0x34 NO DACA1OFFCAL DACA1OFFCAL[7:0] 45
+0x35 NO DACA1GAINCAL DACA1GAINCAL[7:0] 45
+0x36 NO DACB1OFFCAL DACB1OFFCAL[7:0] 46
+0x37 NO DACB1GAINCAL DACB1GAINCAL[7:0] 46
+0x38 Reserved – – – – – – – –
+0x39 Reserved
– – – – – – – –
0x3A Reserved – – – – – – – –
+0x3B Reserved
– – – – – – – –
+0x3C Reserved
– – – – – – – –
+0x3D Reserved – – – – – – – –
+0x3E Reserved
– – – – – – – –
