Atmel AVR XMEGA AU series User Manual

205
8331B–AVR–03/12
Atmel AVR XMEGA AU
15.11 Register Summary
15.12 Interrupt Vector Summary
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 CTRLA – – – – CLKSEL[3:0] 199
+0x01 CTRLB HCMPDEN HCMPCEN HCMPBEN HCMPAEN LCMPDEN LCMPCEN LCMPBEN LCMPAEN 199
+0x02 CTRLC HCMPD HCMPC HCMPB HCMPA LCMPD LCMPC LCMPB LCMPA 200
+0x03 Reserved – – – – – – – –
+0x04 CTRLE – – – – – – BYTEM[1:0] 200
+0x05 Reserved – – – – – – – –
+0x06 INTCTRLA – – – – HUNFINTLVL[1:0] LUNFINTLVL[1:0] 200
+0x07 INTCTRLB LCMPDINTLVL[1:0] LCMPCINTLVL[1:0] LCMPBINTLVL[1:0] LCMPAINTLVL[1:0] 201
+0x08 Reserved – – – – – – – –
+0x09 CTRLF – – – – CMD[1:0] CMDEN[1:0] 201
+0x0A Reserved – – – – – – – –
+0x0B Reserved – – – – – – – –
+0x0C INTFLAGS LCMPDIF LCMPCIF LCMPBIF LCMPAIF – – HUNFIF LUNFIF 202
+0x0D Reserved – – – – – – – –
+0x0E Reserved
– – – – – – – –
+0x0F Reserved
– – – – – – – –
+0x10 to +0x1F Reserved – – – – – – – –
+0x20 LCNT Low-byte Timer/Counter Count Register 203
+0x21 HCNT High-byte Timer/Counter Count Register 203
+0x22 to +0x25 Reserved – – – – – – – –
+0x26 LPER Low-byte Timer/Counter Period Register 203
+0x27 HPER High-byte Timer/Counter Period Register 204
+0x28 LCMPA Low-byte Compare Register A 203
+0x29 HCMPA High-byte Compare Register A 204
+0x2A LCMPB Low-byte Compare Register B 203
+0x2B HCMPB High-byte Compare Register B 204
+0x2C LCMPC Low-byte Compare Register C 203
+0x02D HCMPC High-byte Compare Register C 204
+0x2E LCMPD Low-byte Compare Register D 203
+0x2F HCMPD High-byte Compare Register D 204
+0x30 to +0x3F Reserved – – – – – – – –
Table 15-6. Timer/counter interrupt vectors and their word offset addresses.
Offset Source Interrupt Description
0x00 LUNF_vect Low-byte Timer/counter underflow interrupt vector offset
0x02 HUNF_vect High-byte Timer/counter underflow interrupt vector offset
0x4 LCMPA_vect Low-byte Timer/counter compare channel A interrupt vector offset
0x6 LCMPB_vect Low-byte Timer/counter compare channel B interrupt vector offset
0x8 LCMPC_vect Low-byte Timer/counter compare channel C interrupt vector offset
0x0A LCMPD_vect Low-byte Timer/counter compare channel D interrupt vector offset
