Atmel AVR XMEGA AU series User Manual

204
8331B–AVR–03/12
Atmel AVR XMEGA AU
15.10.14 HCMPx – High-byte Compare register x
• Bit 7:0 – HCMPx[7:0], x=[A, B, C, D]
HCMPx contains the eight-bit compare value for the high-byte timer/counter.
These registers are all continuously compared to the counter value. Normally the outputs from
the comparators are then used for generating waveforms.
Bit 76543210
HCMPx[7:0] HCMPx
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
