Atmel AVR XMEGA AU series User Manual

216
8331B–AVR–03/12
Atmel AVR XMEGA AU
• Bit 7:0 – OUTOVEN[7:0]: Output Override Enable
These bits enable override of the corresponding port output register (i.e., one-to-one bit relation
to pin position). The port direction is not overridden.
16.8 Register Summary
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 CTRL – – PGM CWCM DTICDAEN DTICCCEN DTICCBEN DTICCAEN 212
+0x01 Reserved – – – – – – – –
+0x02 FDEMASK FDEVMASK[7:0] 212
+0x03 FDCTRL – – –FDDBD– FDMODE FDACT[1:0] 212
+0x04 STATUS – – – – – FDF DTBHSV DTBLSV 213
+0x05 Reserved – – – – – – – –
+0x06 DTBOTH DTBOTH[7:0] 214
+0x07 DTBOTHBUF DTBOTHBUF[7:0] 214
+0x08 DTLS DTLS[7:0] 214
+0x09 DTHS DTHS[7:0] 215
+0x0A DTLSBUF DTLSBUF[7:0] 215
+0x0B DTHSBUF DTHSBUF[7:0] 215
+0x0C OUTOVEN OUTOVEN[7:0] 215
