26.7 Register Description
26.7.1 CTRL – Control register
• Bit 7:6 – RESET[1:0]: Reset
These bits are used to reset the CRC module, and they will always be read as zero. The CRC
registers will be reset one peripheral clock cycle after the RESET[1] bit is set.
• Bit 5 – CRC32: CRC-32 Enable
Setting this bit will enable CRC-32 instead of the default CRC-16. It cannot be changed while the
BUSY flag is set.
• Bit 4 – Reserved
This bit is unused and reserved for future use. For compatibility with future devices, always write
this bit to zero when this register is written.
• Bit 3:0 – SOURCE[3:0]: Input Source
These bits select the input source for generating the CRC. The selected source is locked until
either the CRC generation is completed or the CRC module is reset. CRC generation complete
is generated and signaled from the selected source when used with the DMA controller or flash
memory.
Bit 76543210
+0x00 RESET[1:0] CRC32 – SOURCE[3:0] CTRL
Read/Write R/W R/W R/W R R/W R/W R/W R/W
Initial Value00000000
Table 26-1. CRC reset.
RESET[1:0] Group configuration Description
00 NO No reset
01 — Reserved
10 RESET0 Reset CRC with CHECKSUM to all zeros
11 RESET1 Reset CRC with CHECKSUM to all ones
Table 26-2. CRC source select .
SOURCE[3:0] Group configuration Description
0000 DISABLE CRC disabled
0001 IO I/O interface
0010 FLASH Flash
0011 — Reserved for future use
0100 DMACH0 DMA controller channel 0
0101 DMACH1 DMA controller channel 1
