Atmel AVR XMEGA AU series User Manual

82
8331B–AVR–03/12
Atmel AVR XMEGA AU
6.9 Register Summary
Address
Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
+0x00 CH0MUX CH0MUX[7:0] 78
+0x01 CH1MUX CH1MUX[7:0] 78
+0x02 CH2MUX CH2MUX[7:0] 78
+0x03 CH3MUX CH3MUX[7:0] 78
+0x04 CH4MUX CH4MUX[7:0] 78
+0x05 CH5MUX CH5MUX[7:0] 78
+0x06 CH6MUX CH6MUX[7:0] 78
+0x07 CH7MUX CH7MUX[7:0] 78
+0x08 CH0CTRL – QDIRM[1:0] QDIEN QDEN DIGFILT[2:0] 80
+0x09 CH1CTRL – – – – – DIGFILT[2:0] 80
+0x0A CH2CTRL – QDIRM[1:0] QDIEN QDEN DIGFILT[2:0] 80
+0x0B CH3CTRL – – – – – DIGFILT[2:0] 80
+0x0C CH4CTRL – QDIRM[1:0] QDIEN QDEN DIGFILT[2:0] 80
+0x0D CH5CTRL – – – – – DIGFILT[2:0] 80
+0x0E CH6CTRL – – – – – DIGFILT[2:0] 80
+0x0F CH7CTRL – – – – – DIGFILT[2:0] 80
+0x10 STROBE STROBE[7:0] 81
+0x11 DATA DATA[7:0] 81
