463
8331B–AVR–03/12
Atmel AVR XMEGA AU
36.2 SRAM 3-Port ALE12 CS
Figure 36-5. Write, no ALE
Figure 36-6. Write, ALE1
A[7:0]/A[15:8]/A[23:16]
D[7:0]
D[7:0]
A[7:0]
ALE1
Write, no ALE
ALE2
Clk
PER2
RE
WE
CS
D[7:0]
D[7:0]
A[7:0]
ALE1
Write, ALE1
A[15:8]
ALE2
A[7:0]/A[15:8]/A[23:16]
Clk
PER2
RE
WE
CS
