80
8331B–AVR–03/12
Atmel AVR XMEGA AU
6.8.2 CHnCTRL – Event Channel n Control register
• Bit 7 – Reserved
This bit is reserved and will always be read as zero. For compatibility with future devices, always
write this bit to zero when this register is written.
• Bit 6:5 – QDIRM[1:0]: Quadrature Decode Index Recognition Mode
These bits determine the quadrature state for the QDPH0 and QDPH90 signals, where a valid
index signal is recognized and the counter index data event is given according to Table 6-5 on
page 80. These bits should only be set when a quadrature encoder with a connected index sig-
nal is used.These bits are available only for CH0CTRL, CH2CTRL, and CH4CTRL.
• Bit 4 – QDIEN: Quadrature Decode Index Enable
When this bit is set, the event channel will be used as a QDEC index source, and the index data
event will be enabled.
This bit is available only for CH0CTRL, CH2CTRL, and CH4CTRL.
• Bit 3 – QDEN: Quadrature Decode Enable
Setting this bit enables QDEC operation.
This bit is available only for CH0CTRL, CH2CTRL, and CH4CTRL.
• Bit 2:0 – DIGFILT[2:0]: Digital Filter Coefficient
These bits define the length of digital filtering used. Events will be passed through to the event
channel only when the event source has been active and sampled with the same level for the
number of peripheral clock cycles defined by DIGFILT.
1 0 1 TCxn_CCB Capture or compare B (x = C, D, E or F) (n= 0 or 1)
1 1 0 TCxn_CCC Capture or compare C (x = C, D, E or F) (n= 0)
1 1 1 TCxn_CCD Capture or compare D (x = C, D, E or F) (n= 0)
Table 6-4. Timer/counter events. (Continued)
T/C Event E Group Configuration Event Type
Bit 76543210
– QDIRM[1:0] QDIEN QDEN DIGFILT[2:0] CHnCTRL
Read/Write R R/W R/W R/W R/W R/W R/W R
Initial Value00000000
Table 6-5. QDIRM bit settings.
QDIRM[1:0] Index Recognition State
0 0 {QDPH0, QDPH90} = 0b00
0 1 {QDPH0, QDPH90} = 0b01
1 0 {QDPH0, QDPH90} = 0b10
1 1 {QDPH0, QDPH90} = 0b11
