AudioCodes Mediant 1000B - Digit Collection and Dial Plan Parameters

Version 7.2 1117 Mediant 1000B Gateway & E-SBC
User's Manual 65. Configuration Parameters Reference
Parameter Description
PSTN (i.e., not sent as Keypad).
 [1] During Call Establishment = DTMF digits after * or #
(inclusive) are sent as Keypad only during call
establishment and call disconnect. During an established
call, all digits are sent as DTMF.
 [2] Always = DTMF digits after * or # (inclusive) are
always sent as Keypad (call establishment, connect, and
disconnect).
For more information, see Interworking Keypad DTMFs for
SIP-to-ISDN Calls on page 570.
Note:
 This feature is not applicable to re-INVITE messages.
 The parameter is applicable only to digital interfaces.
65.10.3 Digit Collection and Dial Plan Parameters
The digit collection and dial plan parameters are described in the table below.
Table 65-40: Digit Collection and Dial Plan Parameters
Parameter Description
Dial Plan Index
configure voip > gateway
dtmf-supp-service dtmf-and-
dialing > dial-plan-index
[DialPlanIndex]
Defines the Dial Plan index to use in the external Dial Plan file. The
Dial Plan file is loaded to the device as a .dat file (converted using the
DConvert utility). The Dial Plan index can be defined globally or per
Tel Profile.
The valid value range is 0 to 7, where 0 denotes PLAN1, 1 denotes
PLAN2, and so on. The default is -1, indicating that no Dial Plan file is
used.
Note:
 If the parameter is configured to select a Dial Plan index, the
settings of the parameter DigitMapping are ignored.
 If the parameter is configured to select a Dial Plan index from an
external Dial Plan file, the device first attempts to locate a matching
digit pattern in the Dial Plan file, and if not found, then attempts to
locate a matching digit pattern in the Digit Map rules configured by
the DigitMapping parameter.
 The parameter is also applicable to ISDN with overlap dialing.
 For E1 CAS MFC-R2 variants (which don't support terminating digit
for the called party number, usually I-15), the parameter and the
DigitMapping parameter are ignored. Instead, you can define a Dial
Plan template per trunk using the parameter
CasTrunkDialPlanName_x (or in the Trunk Settings page).
 The parameter can also be configured in a Tel Profile.
 For more information on the Dial Plan file, see ''Dialing Plans for
Digit Collection'' on page 797.
configure voip > gateway
manipulation settings >
tel2ip-src-nb-map-dial-index
[Tel2IPSourceNumberMappi
Defines the Dial Plan index in the external Dial Plan file for the Tel-to-
IP Source Number Mapping feature.
The valid value range is 0 to 7, defining the Dial Plan index [Plan x] in
the Dial Plan file. The default is -1 (disabled).
