User's Manual 148 Document #: LTRT-27055
Mediant 1000B Gateway & E-SBC
Destination Prefix Length Gateway
176.85.49.0 24 192.168.11.1
3. All other parameters are set to their respective default values. The NTP application
remains with its default application types.
12.5.3.3 VoIP Interfaces for Combined Application Types
This example describes the configuration of multiple interfaces for the following
applications:
One interface for the OAMP application.
Interfaces for Call Control and Media applications, where two of them are IPv4
interfaces and one is an IPv6 interface.
1. IP Interfaces table:
Table 12-10: Example of VoIP Interfaces of Combined Application Types in IP Interfaces table
Inde
x
Applicatio
n Type
Interfac
e Mode
IP Address
Prefix
Lengt
h
Default
Gateway
Etherne
t
Device
Name
0 OAMP IPv4
Manual
192.168.0.2 16 192.168.0.1 1 Mgmt
1 Media &
Control
IPv4
Manual
200.200.85.14 24 200.200.85.
1
201 MediaCntrl1
2 Media &
Control
IPv4
Manual
200.200.86.14 24 200.200.86.
1
202 MediaCntrl2
3 Media &
Control
IPv6
Manual
2000::1:200:200:86:1
4
64 :: 202 V6CntrlMedia
2
2. Static Routes table: A routing rule is required to allow remote management from a
host in 176.85.49.0/24:
Table 12-11: Example of Static Routes Table
Destination Prefix Length Gateway
176.85.49.0 24 192.168.0.10
3. The NTP application is configured (through the ini file) to serve as OAMP applications:
EnableNTPasOAM = 1
4. DiffServ table:
• Layer-2 QoS values are assigned:
♦ For packets sent with DiffServ value of 46, set VLAN priority to 6
♦ For packets sent with DiffServ value of 40, set VLAN priority to 6
♦ For packets sent with DiffServ value of 26, set VLAN priority to 4
♦ For packets sent with DiffServ value of 10, set VLAN priority to 2
• Layer-3 QoS values are assigned:
♦ For Media Service class, the default DiffServ value is set to 46
♦ For Control Service class, the default DiffServ value is set to 40
