AudioCodes Mediant 1000B User Manual

Version 7.2 903 Mediant 1000B Gateway & E-SBC
User's Manual 54. Viewing VoIP Status
54.7 Viewing SBC CDR History
You can view historical Call Detail Records (CDR) of SBC calls in a table. History CDRs
are stored on the device’s memory. When a new CDR is generated, the device adds it to
the top of the table and all existing entries are shifted one down in the table. The table
displays the last 4,096 CDRs. If the table reaches maximum capacity of entries and a new
CDR is added, the last CDR entry is removed from the table.
Note: If the device is reset, all CDRs are deleted from memory and from the table.
 To view SBC CDR history:

Web: Open the SBC CDR History table (Monitor menu > Monitor tab > VoIP Status
folder > SBC CDR History).
Figure 54-6: SBC CDR History Table

CLI:
• All CDR history:
# show voip calls history sbc
• CDR history for a specific SIP session ID:
# show voip calls history sbc <session ID>
Table 54-7: SBC CDR History Table
Field Description
Call End Time
Displays the time at which the call ended. The time is displayed in the
format, hh:mm:ss, where hh is the hour, mm the minutes and ss the
seconds (e.g., 15:06:36).
IP Group
Displays the IP Group of the leg for which the CDR was generated.
Caller
Displays the phone number (source URI user@host) of the party who
made the call.
Callee
Displays the phone number (destination URI user@host) of the party to
whom the call was made.
Direction
Displays the direction of the call:
 "Incoming"
 "Outgoing"
Remote IP
Displays the IP address of the call party. For an "Incoming" call, this is
the source IP address; for an "Outgoing" call, this is the destination IP
address.
Duration
Displays the duration of the call, displayed in the format hh:mm:ss,
where hh is hours, mm minutes and ss seconds. For example, 00:01:20
