62 Analog Line Testing
62.1 FXS Line Testing
You can test FXS telephone lines that are connected to the device's FXS ports. The test is
done per FXS port and FXS country coefficient type - USA (70) or TBR21 (66). The output
of the test displays various line statuses and electrical line measurements. Some of the
supported FXS status and line measurements include:

Hazardous Potential Tests (HPT) - hazardous AC or DC voltage is present on the tip
and ring or both.

Foreign Electromotive Force Tests (FEMT) - foreign voltage is present on the tip, ring
or both

Resistive Fault Tests (RFT) - tip or ring is shorted to ground, or they are shorted to
each other

Receiver Off-hook Tests (ROH) - one or more phones are off hook on phone line
during test.

Ringer Impedance Tests (RIT)

AC/DC line voltage

AC/DC line current

Line resistance

Line capacity

Hook status (on or off)

Message Waiting Indication (MWI) status (on or off)

Ring status (on or off)

Reversal polarity status (on or off)
The FXS line test is currently supported only through CLI.
Note: FXS line testing is supported only by the FXS module type that supports
outdoor FXS cabling.
 To run the FXS line test:
1. Access the VoIP command set:
# configure voip
2. Access the FXS interface command set:
(config-voip)# interface fxs-fxo
3. Type the following command:
(fxs-fxo)# fxs-line-testing < Module/Port > {66|70}
For example, to test FXS port 4 on FXS module 1 with coefficient type USA:
(fxs-fxo)# fxs-line-testing 1/4 70
