AudioCodes Mediant 1000B - Pre-Configured IP-To-IP Routing Rules; Normal Mode

User's Manual 772 Document #: LTRT-27055
Mediant 1000B Gateway & E-SBC
40.4 Pre-Configured IP-to-IP Routing Rules
For the CRP application, the IP-to-IP Routing table is pre-configured with IP-to-IP routing
rules. These rules depend on the configured Call Survivability mode, as described in
''Configuring Call Survivability Mode'' on page 769.
Note:
• The IP-to-IP Routing table is read-only.
• For accessing the IP-to-IP Routing table and for a description of its parameters,
see ''Configuring SBC IP-to-IP Routing Rules'' on page 695.
40.4.1 Normal Mode
The pre-configured IP-to-IP routing rules for the Normal CRP call survivability mode are
shown in the table below:
Table 40-2: Pre-Configured IP-to-IP Routing Rules for CRP Normal Mode
Index Source IP
Group /
Emergency
Request
Type
Destination
Type
Destination
IP Group
Destination
Address
Alternative Route
Options
1 Any OPTIONS Dest
Address
- Internal Route Row
3 #1 [CRP
Users]
All IP Group #2 [CRP
Proxy]
- Route Row
4 #1 [CRP
Users]
All IP Group #1 [CRP
Users]
- Alternative Route
Ignore Inputs
5 #1 [CRP
Users]
All IP Group #3 [CRP
Gateway]
- Alternative Route
Ignore Inputs
6 #2 [CRP
Proxy]
All IP Group #1 [CRP
Users]
- Route Row
7 #2 [CRP
Proxy]
All IP Group #3 [CRP
Gateway]
- Route Row
8 #3 [CRP
Gateway]
All IP Group #2 [CRP
Proxy]
- Route Row
9 #3 [CRP
Gateway]
All IP Group #1 [CRP
Users]
- Alternative Route
Ignore Inputs
Note: Index 7 appears only if the CRPGatewayFallback parameter is enabled (see
'Configuring PSTN Fallback' on page 774). This routing rule is used if the device can't
find a matching destination user for IP Group 1 (User-type IP Group) in its registration
database. If the CRPGatewayFallback parameter is disabled and no matching user is
find, the device rejects the call.
