AudioCodes Mediant 1000B - Page 274

User's Manual 274 Document #: LTRT-27055
Mediant 1000B Gateway & E-SBC
Services folder > Remote Web Services).
2. Click New; the following dialog box appears:
Figure 15-40: Remote Web Services Table - Add Dialog Box
3. Configure a remote Web service according to the parameters described in the table
below.
4. Click Apply, and then save your settings to flash memory.
Table 15-18: Remote Web Services Table Parameter Descriptions
Parameter Description
General
Index
[HTTPRemoteServices_Index]
Defines an index number for the new table row.
Note:
 Each row must be configured with a unique index.
 The parameter is mandatory.
Name
rest-name
[HTTPRemoteServices_Name]
Defines a descriptive name, which is used when associating the
row in other tables.
The valid value is a string of up to 40 characters.
Note:
 Each row must be configured with a unique name.
 The parameter is mandatory.
Type
rest-message-type
[HTTPRemoteServices_HTTPT
ype]
Defines the type of service provided by the HTTP remote host:
 [0] Routing (default) = Routing service (also includes Call Status
and Topology Status).
 [1] Call Status = Call status service.
 [2] Topology Status = Topology status service (e.g., change in
configuration).
 [3] Capture = Recording of signaling and RTP packets, which
can be sent to a remote host, for example, to a Syslog server or
AudioCodes SEM.
