User's Manual 328 Document #: LTRT-27055
Mediant 1000B Gateway & E-SBC
2. Click New; the following dialog box appears:
Figure 17-1: Media Realms Table - Add Dialog Box
3. Configure the Media Realm according to the parameters described in the table below.
4. Click Apply.
Table 17-1: Media Realms table Parameter Descriptions
Parameter Description
General
Index
[CpMediaRealm_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
name
[CpMediaRealm_MediaRealmName]
Defines a descriptive name, which is used when associating
the row in other tables.
The valid value is a string of up to 40 characters.
Note:
The parameter is mandatory.
Each row must be configured with a unique name.
Topology Location
topology-location
[CpMediaRealm_TopologyLocation]
Defines the display location of the Media Realm in the
Topology view.
[0] Down = (Default) The Media Realm element is displayed
on the lower border of the view.
[1] Up = The Media Realm element is displayed on the
upper border of the view.
For more information on the Topology view, see ''Building and
Viewing SIP Entities in Topology View'' on page 377.
IPv4 Interface Name
ipv4
[CpMediaRealm_IPv4IF]
Assigns an IPv4 network interface to the Media Realm.
By default, no value is defined.
To configure IP network interfaces, see ''Configuring IP
Network Interfaces'' on page 142.
