Version 7.2 691 Mediant 1000B Gateway & E-SBC
User's Manual 34. Routing SBC
2. Click New; the following dialog box appears:
Figure 34-3: Classification Table - Add Dialog Box
3. Configure the Classification rule according to the parameters described in the table
below.
4. Click Apply.
Table 34-1: Classification Table Parameter Descriptions
Parameter Description
SRD
srd-name
[Classification_SRDName]
Assigns an SRD to the rule as a matching characteristic for the
incoming SIP dialog.
If only one SRD is configured in the SRDs table, the SRD is assigned
to the rule by default. If multiple SRDs are configured in the SRDs
table, no value is assigned.
To configure SRDs, see ''Configuring SRDs'' on page 335.
Note: The parameter is mandatory.
Match
Index
[Classification_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
classification-name
[Classification_Classification
Name]
Defines a descriptive name, which is used when associating the row in
other tables.
The valid value is a string of up to 40 characters. By default, no name
is defined.
Note: Each row must be configured with a unique name.
Source SIP Interface
src-sip-interface-name
[Classification_SrcSIPInterfa
Assigns a SIP Interface to the rule as a matching characteristic for the
incoming SIP dialog.
The default is Any (i.e., all SIP Interfaces belonging to the SRD
