Version 7.2 717 Mediant 1000B Gateway & E-SBC
User's Manual 34. Routing SBC
the device associates the call to the SRD that is assigned to the SIP Interface.
2. Once the call has been successfully classified to an IP Group, the Routing Policy
assigned to the associated SRD is used. However, if a Routing Policy is configured in
the Classification table, it overrides the Routing Policy assigned to the SRD.
3. The regular manipulation (inbound and outbound) and routing processes are done
according to the associated Routing Policy.
Note:
• The Classification table is used only if classification by registered user in the
device's users registration database or by Proxy Set fails.
• If the device receives incoming calls (e.g., INVITE) from users that have already
been classified and registered in the device's registration database, the device
ignores the Classification table and uses the Routing Policy that was determined
for the user during the initial classification process.
The following procedure describes how to configure Routing Policies rules through the
Web interface. You can also configure it through ini file (SBCRoutingPolicy) or CLI
(configure voip > sbc routing sbc-routing-policy).
To configure a Routing Policy rule:
1. Open the Routing Policies table (Setup menu > Signaling & Media tab > SBC folder
> Routing > Routing Policies).
2. Click New; the following dialog box appears:
Figure 34-7: Routing Policies Table - Add Dialog Box
3. Configure the Routing Policy rule according to the parameters described in the table
below.
4. Click Apply.
