CHAPTER13 Network
Mediant 800 Gateway & E-SBC | User's Manual
➢ To configure IP network interfaces:
1. Open the IP Interfaces table (Setup menu > IP Network tab > Core Entities folder > IP
Interfaces).
2. Click New; the following dialog box appears:
3. Configure the IP network interface according to the parameters described in the table below.
4. Click Apply.
● If you modify the OAMP interface's address, after clicking Apply you will lose
connectivity with the device and need to access the device with the new address.
● If you edit or delete an IP interface, current calls using the interface are immediately
terminated.
● If you delete an IP interface, row indices of other tables (e.g., Media Realms table)
that are associated with the deleted IP interface, lose their association with the
interface ('Interface Name' field displays "None") and the row indices become
invalid.
● If you edit or delete the Maintenance interface (for HA mode), you must reset the
device for your changes to take effect.
To view configured IP network interfaces that are currently active, click the IP Interface Status
Table link located at the bottom of the table. For more information, see Viewing Active IP
Interfaces.
Table 13-5: IP Interfaces Table Parameters Description
Parameter Description
General
'Index'
network-if
[InterfaceTable_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Name'
name
[InterfaceTable_InterfaceName]
Defines a name for the interface.
The valid value is a string of up to 16 characters. The
default (if no name is configured) is "Interface_n", where n
is the row index number.
Note:
■ Each row must be configured with a unique name.
