CHAPTER16 Services
Mediant 800 Gateway & E-SBC | User's Manual
The following configuration records calls made by IP Group "ITSP" to IP Group "IP-PBX" that
have the destination number prefix "1800". The device records the calls from the leg interfacing
with IP Group "IP PBX" (peer) and sends the recorded media to IP Group "SRS-1". SRS
redundancy has also been configured, where IP Group "SRS-1" is the active SRS and IP Group
"SRS-2" the standby SRS.
● Recorded IP Group: "ITSP"
● Recorded Destination Pattern: 1800
● Peer IP Group: "IP-PBX"
● Caller: Peer Party
● Recording Server (SRS) IP Group: "SRS-1"
● Recording Server (SRS) IP Group: "SRS-2"
1. Configure a SIP recording rule according to the parameters described in the table below.
2. Click Apply, and then save your settings to flash memory.
Table 16-6: SIP Recording Rules Table Parameter Descriptions
Parameter Description
General
'Index'
[SIPRecRouting_Index]
Defines an index number for the new table record.
'Recorded IP Group'
recorded-ip-group-name
[SIPRecRouting_
RecordedIPGroupName]
Defines the IP Group participating in the call and the
recording is done on the leg interfacing with this IP Group. To
configure IP Groups, see Configuring IP Groups.
By default, all IP Groups are defined (Any).
Note:
■ The parameter is mandatory.
■ For an SBC RTP-SRTP session, the recorded IP Group
must be set to the RTP leg if recording is required to be
RTP, or set to the SRTP leg if recording is required to be
SRTP.
'Recorded Source Pattern'
recorded-src-pattern
[SIPRecRouting_
RecordedSourcePrefix]
Defines calls to record based on source number or SIP URI.
You can use special patterns (notations) to denote the
number or URI. For example, if you want to match this rule
to user parts whose last four digits (i.e., suffix) are 4 followed
by any three digits (e.g., 4008), then configure this parameter
to "(4xxx)". For available patterns, see Patterns for Denoting
Phone Numbers and SIP URIs on page1148.
