Automation Direct DURApulse GS4 User Manual

Page 4–22
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
GS4 Parameters Summary – Display Parameters (P8.xx) – (continued)
Parameter Range
Run
Read/
Write
Modbus
Address
Settings
Hex Dec Default User
P8.02
User Defined Format
Bi ts 0~3: User defined decimal place:
0000b: no decimal place
0001b: one decimal place
0010b: two decimal place
0011b: three decimal place
Bi ts 4~9: User defined unit:
000xh: Hz
001xh: rpm
002xh: %
003xh: kg
004xh: m/s
005xh: kW
006xh: hp
007xh: ppm
008xh: 1/m
009xh: kg/s
00Axh: kg/m
00Bxh: kg/h
00Cxh: lb/s
00Dxh: lb/m
00Exh: lb/h
00Fxh: ft/s
010xh: ft/m
011xh: m
012xh: ft
013xh: °C
014xh: °F
015xh: mbar
016xh: bar
017xh: Pa
018xh: kPa
019xh: mWG
01Axh: inWG
01Bxh: ftWG
01Cxh: psi
01Dxh: atm
01Exh: L/s
01Fxh: L/m
020xh: L/h
021xh: m
3
/s
022xh: m
3
/h
023xh: gpm
024xh: cfm
R/W 0802 42051 0
P8.03
User Defined Max
0: Disable
0~65535 (when P8�02 set to no decimal place)
0�0~6553�5 (when P8�02 set to 1 decimal
place)
0�00~655�35 (when P8�02 set to 2 decimal
place)
0�000~65�535 (when P8�02 set to 3 decimal
place)
R/W 0803 42052 0
P8.04
User Defined Setpoint 0~65535 Read 0804 42053 0 ~
P8.05
Output Frequency Gain 0�00~160�00 R/W 0805 42054 1�00
P8.06
Password Input 0~65535 ♦ R/W 0806 42055 0
P8.07
Password Set Up 0~65535 ♦ R/W 0807 42056 0
P8.08
Power On Counter 0~65535 Read 0808 42057 ~ ~
P8.09
Power On Day 0~65535 Read 0809 42058 ~ ~
P8.10
Power On Minute 0~1439 Read 080A 42059 ~ ~
(table continued next page)
