Chapter 4: AC Drive Parameters
Page 4–25
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
GS4 Parameters Summary – Serial Communication Parameters (P9.xx) – (continued)
Parameter Range
Run
Read/
Write
Modbus
Address
Settings
Hex Dec Default User
P9.09
Block Transfer Data Location 1
0~65535
* P9�09~P9�24 can be set in run mode
if the corresponding Block Transfer
Address Pointer (P9�69~P9�84) is
pointing to a register that allows
writes while in run mode�
* R/W
0909 42314
200
P9.10
Block Transfer Data Location 2 090A 42315
P9.11
Block Transfer Data Location 3 090B 42316
P9.12
Block Transfer Data Location 4 090C 42317
P9.13
Block Transfer Data Location 5 090D 42318
P9.14
Block Transfer Data Location 6 090E 42319
P9.15
Block Transfer Data Location 7 090F 42320
P9.16
Block Transfer Data Location 8 0910 42321
P9.17
Block Transfer Data Location 9 0911 42322
P9.18
Block Transfer Data Location 10 0912 42323
P9.19
Block Transfer Data Location 11 0913 42324
P9.20
Block Transfer Data Location 12 0914 42325
P9.21
Block Transfer Data Location 13 0915 42326
P9.22
Block Transfer Data Location 14 0916 42327
P9.23
Block Transfer Data Location 15 0917 42328
P9.24
Block Transfer Data Location 16 0918 42329
P9.25
reserved n/a n/a 0919 42330 n/a
P9.26
RS485 Speed Reference 0�00~600�00 Hz Read 091A 42331 60�00 ~
P9.27
RS485 RUN Command
0: Stop
1: Run
♦ R/W 091B 42332 0
P9.28
RS485 Direction Command
0: Forward
1: Reverse
♦ R/W 091C 42333 0
P9.29
RS485 External Fault
0: No Fault
1: External Fault
♦ R/W 091D 42334 0
P9.30
RS485 Fault Reset
0: No Action
1: Fault Reset
♦ R/W 091E 42335 0
P9.31
RS485 JOG Command
0: Stop
1: Jog
♦ R/W 091F 42336 0
P9.32
reserved n/a n/a 0920 42337 n/a
P9.33
GS4 Drive Rated Amps 0�00~655�34A Read 0921 42338 #�## ~
P9.34
PLC Command Mask (status only) 0~65535 Read 0922 42339 0 ~
P9.35
Response Delay Time 0�0~200�0 ms ♦ R/W 0923 42340 2�0
P9.36
reserved n/a n/a 0924 42341 n/a
P9.37
PLC Address 1~254 R/W 0925 42342 2
P9.38
Firmware Date Code
Format: yywwd
• yy = year (2017 = 17)
• ww = week (1~52)
• d = day of week (1~7; Mon=1, Fri=5)
Read 0926 42343 #####
P9.39
Firmware version x�xx Read 0927 42344 #�## ~
P9.40
reserved n/a n/a 0928 42345 n/a
P9.41
GS Series Number 0~9 Read 0929 42346 4
(table continued next page)
