Automation Direct DURApulse GS4 User Manual

Page 4–26
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
GS4 Parameters Summary – Serial Communication Parameters (P9.xx) – (continued)
Parameter Range
Run
Read/
Write
Modbus
Address
Settings
Hex Dec Default User
P9.42
GS Model ID
00: GS4-21P0 (230V 1ph/3ph 1�0hp)
01: GS4-22P0 (230V 1ph/3ph 2�0hp)
02: GS4-23P0 (230V 1ph/3ph 3�0hp)
03: GS4-25P0 (230V 3ph 5�0hp)
04: GS4-27P5 (230V 3ph 7�5hp)
05: GS4-2010 (230V 3ph 10hp)
06: GS4-2015 (230V 3ph 15hp)
07: GS4-2020 (230V 3ph 20hp)
08: GS4-2025 (230V 3ph 25hp)
09: GS4-2030 (230V 3ph 30hp)
10: GS4-2040 (230V 3ph 40hp)
11: GS4-2050 (230V 3ph 50hp)
12: GS4-2060 (230V 3ph 60hp)
13: GS4-2075 (230V 3ph 75hp)
14: GS4-2100 (230V 3ph 100hp)
15: GS4-41P0 (460V 3ph 1�0hp)
16: GS4-42P0 (460V 3ph 2�0hp)
17: GS4-43P0 (460V 3ph 3�0hp)
18: GS4-45P0 (460V 3ph 5�0hp)
19: GS4-47P5 (460V 3ph 7�5hp)
20: GS4-4010 (460V 3ph 10hp)
21: GS4-4015 (460V 3ph 15hp)
22: GS4-4020 (460V 3ph 20hp)
23: GS4-4025 (460V 3ph 25hp)
24: GS4-4030 (460V 3ph 30hp)
25: GS4-4040 (460V 3ph 40hp)
26: GS4-4050 (460V 3ph 50hp)
27: GS4-4060 (460V 3ph 60hp)
28: GS4-4075 (460V 3ph 75hp)
29: GS4-4100 (460V 3ph 100hp)
30: GS4-4125 (460V 3ph 125hp)
31: GS4-4150 (460V 3ph 150hp)
32: GS4-4175 (460V 3ph 175hp)
33: GS4-4200 (460V 3ph 200hp)
34: GS4-4250 (460V 3ph 250hp)
35: GS4-4300 (460V 3ph 300hp)
Read 092A 42347 ##
P9.43
Ignore Comm Card Warning
0: Disable function (do NOT ignore)
1: Enable function (ignore warning)
1 092B 42348 1
P9.44
Comm Card Type
0: No Communication Card
1: reserved
2: reserved
3: reserved
4: MODBUS-TCP Slave
5: EtherNet/IP Slave
6: reserved
7: reserved
8: reserved
Read 092C 42349 0 ~
P9.45
Comm Card Version 0~65535 Read 092D 42350 0 ~
P9.46
Comm Card Production Code 0~65535 Read 092E 42351 0 ~
P9.47
Comm Card Fault Code 0~65535 Read 092F 42352 0 ~
P9.48
Comm Card IP Configuration
0: Static IP
1: Dynamic IP (DHCP)
R/W 0930 42353 0
P9.49
Comm Card IP Address Octet 1 0~255 R/W 0931 42354 0
P9.50
Comm Card IP Address Octet 2 0~255 R/W 0932 42355 0
P9.51
Comm Card IP Address Octet 3 0~255 R/W 0933 42356 0
P9.52
Comm Card IP Address Octet 4 0~255 R/W 0934 42357 0
P9.53
Comm Card Mask Octet 1 0~255 R/W 0935 42358 0
P9.54
Comm Card Mask Octet 2 0~255 R/W 0936 42359 0
