Automation Direct DURApulse GS4 User Manual

Chapter 4: AC Drive Parameters
Page 4–27
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
GS4 Parameters Summary – Serial Communication Parameters (P9.xx) – (continued)
Parameter Range
Run
Read/
Write
Modbus
Address
Settings
Hex Dec Default User
P9.55
Comm Card Mask Octet 3 0~255 R/W 0937 42360 0
P9.56
Comm Card Mask Octet 4 0~255 R/W 0938 42361 0
P9.57
Comm Card Gateway Octet 1 0~255 R/W 0939 42362 0
P9.58
Comm Card Gateway Octet 2 0~255 R/W 093A 42363 0
P9.59
Comm Card Gateway Octet 3 0~255 R/W 093B 42364 0
P9.60
Comm Card Gateway Octet 4 0~255 R/W 093C 42365 0
P9.61
reserved ~ ~ 093D 42366 0 ~
P9.62
reserved ~ ~ 093E 42367 0 ~
P9.63
Comm Card Factory Reset
0: No Action
1: Reset to the Factory Setting
R/W 093F 42368 0
P9.64
Comm Card External Set
0, 2
Bit 0 = reserved
Bit 1 = Write Ethernet Parameters to
Comm Card
Bit 2 = reserved
R/W 0940 42369 0
P9.65
reserved ~ ~ 0941 42370 0
P9.66
reserved ~ ~ 0942 42371 ~ ~
P9.67
reserved ~ ~ 0943 42372 ~ ~
P9.68
reserved ~ ~ 0944 42373 ~ ~
P9.69
Block Transfer Address Pointer 1
0~65535 ♦ R/W
0945 42374 0
P9.70
Block Transfer Address Pointer 2 0946 42375 0
P9.71
Block Transfer Address Pointer 3 0947 42376 0
P9.72
Block Transfer Address Pointer 4 0948 42377 0
P9.73
Block Transfer Address Pointer 5 0949 42378 0
P9.74
Block Transfer Address Pointer 6 094A 42379 0
P9.75
Block Transfer Address Pointer 7 094B 42380 0
P9.76
Block Transfer Address Pointer 8 094C 42381 0
P9.77
Block Transfer Address Pointer 9 094D 42382 0
P9.78
Block Transfer Address Pointer 10 094E 42383 0
P9.79
Block Transfer Address Pointer 11 094F 42384 0
P9.80
Block Transfer Address Pointer 12 0950 42385 0
P9.81
Block Transfer Address Pointer 13 0951 42386 0
P9.82
Block Transfer Address Pointer 14 0952 42387 0
P9.83
Block Transfer Address Pointer 15 0953 42388 0
P9.84
Block Transfer Address Pointer 16 0954 42389 0
P9.85
PLC Frequency Command Force
to 0
0~ 1h
Bit 0 = 1: Before PLC scan, set up PLC
Target Frequency = 0
R/W 0955 42390 0
P9.86
COMM1 Protocol (via RS-485)
0: Modbus
1: BACnet
Read 0956 42391 0
P9.87
BACnet Address 0~127 R/W 0957 42392 10
P9.88
BACnet Baud Rate 9�6~76�8 Kbps R/W 0958 42393 38�4
P9.89
BACnet Device Instance Low Word 0~65535 R/W 0959 42394 10
P9.90
BACnet Device Instance High Byte 0~63 R/W 095A 42395 0
P9.91
BACnet Max Polling Address 0~127 R/W 095B 42396 127
P9.92
BACnet Password 0~65535 R/W 095C 42397 0
P9.93
Ethernet Comm Card Fault Select
0: Warn & Continue Operation
1: Warn & Ramp to Stop
2: Warn & Coast to Stop
3: No Warning & Continue Operation
♦ R/W 095D 42398 3
P9.94
Ethernet Comm Card Time Out
Detection
0: Disable
1: Enable
♦ R/W 095E 42399 0
(table continued next page)
