Page 4–38
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
Type Hex Addr Dec Addr
P0.17 Motor 2 Rated Horsepower (HP)
♦R/W 0011 40018
Range/Units (Format: 16-bit unsigned) Default
0�00~655�35 hp
rated hp of GS4
Used to set rated horsepower of Motor 2.
Set the value of this parameter according to the horsepower rating on the motor nameplate.
Type Hex Addr Dec Addr
P0.18 Motor 2 Pole No.
R/W 0012 40019
Range/Units (Format: 16-bit unsigned) Default
2 to (120 x P0�13/P0�14)
4
Used to set the number of motor poles (must be an even number).
For a given Motor 2 Rated RPM (P0.14) value, Motor 2 Pole Number (P0.18) can only be decreased
from the # of poles defined by “# of Poles = (120 x Freq/Base RPM).” The Motor 2 Rated RPM (P0.14)
value must be adjusted to a lower speed before the pole count can be adjusted up.
•
The # of poles must be adjusted down before you can increase the value in P0�14�
•
Rated RPM must be adjusted down before you can increase number of poles�
Motor Synchronous Speed (RPM)
900 1200 1800 3600
Number of Motor Poles (#)
8 6 4 2
