Page 4–142
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
Type Hex Addr Dec Addr
P6.31 Cooling Fan Control
♦R/W 061F 41568
Range/Units (Format: 16-bit binary) Default
0: Always ON (Fan is always ON�)
1: Fan OFF 1 minute after Stop
2: Run fan ON / Stop fan OFF
(Fan is ON when drive runs; fan turns OFF when drive stops�)
3: Heat sink temperature (Fan turns ON when preliminary heat
sink temperature (around 60°C) is attained�)
4: Always OFF (Fan is always OFF�)
0
Type Hex Addr Dec Addr
P6.32 PWM Fan Speed
R/W 0620 41569
Range/Units (Format: 16-bit unsigned) Default
0~100%
60
Adjusts the speed of the internal cooling fan.
To Next Page
