Page 4–160
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
Type Hex Addr Dec Addr
P6.61 Decel Energy Backup (DEB) Decel Selection
♦R/W 063D 41598
Range/Units (Format: 16-bit binary) Default
0: Disable
1: 1st Decel Time
2: 2nd Decel Time
3: 3rd Decel Time
4: 4th Decel Time
5: Current Decel Time
6: Auto Decel Time
0
This parameter is used for the Decel Time Selection for momentary power loss.
Related parameters: P6.61~P6.64; refer to further information following P6.64 (page 4–161).
Type Hex Addr Dec Addr
P6.62 DEB Offset Level
R/W 063E 41599
Range/Units (Format: 16-bit unsigned) Default
230V models: 0�0~100�0 VDC
460V models: 0�0~200�0 VDC
40�0
80�0
The Decel Energy Backup Offset Level is the bias that is added to the DEB Disable Voltage Level
(P6.63) which creates the DEB Activation Level. The DEB Activation Level is the point when the
DEB function is initiated.
Related parameters: P6.61~P6.64; refer to further information following P6.64 (page 4–161).
Type Hex Addr Dec Addr
P6.63 DEB Disable Voltage Level
R/W 063F 41600
Range/Units (Format: 16-bit unsigned) Default
230V models: 0�0~200�0 VDC
460V models: 0�0~400�0 VDC
150�0
300�0
The DEB (Decel Energy Backup) will be disabled when the voltage of the DC Bus is lower than the
setting at P6.63. The drive will then coast to a stop.
Related parameters: P6.61~P6.64; refer to further information following P6.64 (page 4–161).
Type Hex Addr Dec Addr
P6.64 DEB Delay Time
♦R/W 0640 41601
Range/Units (Format: 16-bit unsigned) Default
0�0~25�0 sec
0�0
The drive will not ramp up to commanded speed until the DEB Delay Time has elapsed.
Related parameters: P6.61~P6.64; refer to further information following P6.64 (page 4–161).
