Page 4–186
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 4: AC Drive Parameters
Type Hex Addr Dec Addr
P9.34 PLC Command Mask (status only)
Read 0922 42339
Range/Units (Format: 16-bit binary) Default
0~65535
Bit 0: Control Commands Controlled by PLC
Bit 1: Frequency Commands Controlled by PLC
Bit 2: reserved
Bit 3: reserved
0
This parameter shows if the Source Of Operation Command (SOOC) or the Source of Operation
Frequency (SOOF) is controlled by the internal PLC or controlled by the drive.
Type Hex Addr Dec Addr
P9.35 Response Delay Time
♦ R/W 0923 42340
Range/Units (Format: 16-bit unsigned) Default
0�0~200�0 ms
2�0
This parameter is the response delay time after the AC drive receives a serial Modbus or BACnet
communication command as shown below.
PC or PLC Command
Response Message
of the AC Drive
Handling time
Response Delay
Type Hex Addr Dec Addr
P9.36 reserved
~ 0924 42341
Type Hex Addr Dec Addr
P9.37 PLC Address
R/W 0925 42342
Range/Units (Format: 16-bit unsigned) Default
1~254
2
Modbus node address of the PLC. Cannot be same as the communication address of drive (P9.00).
Type Hex Addr Dec Addr
P9.38 Firmware Date Code
~ 0926 42343
Range/Units Default
Format: yywwd
• yy = year (2017 = 17)
• ww = week (1~52)
• d = day of week (1~7; Mon=1, Fri=5)
#####
Type Hex Addr Dec Addr
P9.39 Firmware version
Read 0927 42344
Range/Units (Format: 16-bit unsigned) Default
x�xx
#�##
This parameter shows the firmware version of the GS4 AC Drive.
To see firmware version of the Keypad instead of the drive, hold the UP key during boot up.
Updating firmware will not change the values of the parameters.
Type Hex Addr Dec Addr
P9.40 reserved
~ 0928 42345
Type Hex Addr Dec Addr
P9.41 GS Series Number
Read 0929 42346
Range/Units Default
0~9
4
