Automation Direct DURApulse GS4 User Manual

Chapter 4: AC Drive Parameters
Page 4–187
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Type Hex Addr Dec Addr
P9.42 Manufacturer Model
Read 092A 42347
Range/Units (Format: 16-bit unsigned) Default
00: GS4-21P0 (230V 1ph/3ph 1�0hp)
01: GS4-22P0 (230V 1ph/3ph 2�0hp)
02: GS4-23P0 (230V 1ph/3ph 3�0hp)
03: GS4-25P0 (230V 3ph 5�0hp)
04: GS4-27P5 (230V 3ph 7�5hp)
05: GS4-2010 (230V 3ph 10hp)
06: GS4-2015 (230V 3ph 15hp)
07: GS4-2020 (230V 3ph 20hp)
08: GS4-2025 (230V 3ph 25hp)
09: GS4-2030 (230V 3ph 30hp)
10: GS4-2040 (230V 3ph 40hp)
11: GS4-2050 (230V 3ph 50hp)
12: GS4-2060 (230V 3ph 60hp)
13: GS4-2075 (230V 3ph 75hp)
14: GS4-2100 (230V 3ph 100hp)
15: GS4-41P0 (460V 3ph 1�0hp)
16: GS4-42P0 (460V 3ph 2�0hp)
17: GS4-43P0 (460V 3ph 3�0hp)
18: GS4-45P0 (460V 3ph 5�0hp)
19: GS4-47P5 (460V 3ph 7�5hp)
20: GS4-4010 (460V 3ph 10hp)
21: GS4-4015 (460V 3ph 15hp)
22: GS4-4020 (460V 3ph 20hp)
23: GS4-4025 (460V 3ph 25hp)
24: GS4-4030 (460V 3ph 30hp)
25: GS4-4040 (460V 3ph 40hp)
26: GS4-4050 (460V 3ph 50hp)
27: GS4-4060 (460V 3ph 60hp)
28: GS4-4075 (460V 3ph 75hp)
29: GS4-4100 (460V 3ph 100hp)
30: GS4-4125 (460V 3ph 125hp)
31: GS4-4150 (460V 3ph 150hp)
32: GS4-4175 (460V 3ph 175hp)
33: GS4-4200 (460V 3ph 200hp)
34: GS4-4250 (460V 3ph 250hp)
35: GS4-4300 (460V 3ph 300hp)
##
This parameter shows the model number and ID code of the GS4 AC Drive. Use this P9.42 ID code
to find the drive rated current in P9.33.
Type Hex Addr Dec Addr
P9.43 Ignore Comm Card Warning
R/W 092B 42348
Range/Units Default
0: Disable Ignore function (do NOT ignore warning)
1: Enable Ignore function (ignore warning)
1
Enabling P9.43 will cause the drive to ignore Comm Card warnings.
Type Hex Addr Dec Addr
P9.44 Comm Card Type
Read 092C 42349
Range/Units (Format: 16-bit binary) Default
0: No Communication Card
1: reserved
2: reserved
3: reserved
4: MODBUS-TCP Slave
5: EtherNet/IP Slave
6: reserved
7: reserved
8: reserved
0
This parameter displays the type of the currently installed communications card.
Type Hex Addr Dec Addr
P9.45 Comm Card Version
Read 092D 42350
Range/Units (Format: 16-bit unsigned) Default
0~65535
0
This parameter displays the firmware version of the currently installed communications card.
Type Hex Addr Dec Addr
P9.46 Comm Card Production Code
Read 092E 42351
Range/Units (Format: 16-bit unsigned) Default
0~65535
0
This parameter displays the production code of the currently installed communications card.
