Automation Direct DURApulse GS4 User Manual

Chapter 4: AC Drive Parameters
Page 4–209
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Example of Drive Fault Records
If the first fault ovA occurs after operation 3000 minute, second fault ovd occurs at 3482 min, third
fault ovA occurs at 4051 min, fourth fault ocA at 5003 min, fifth fault ocA at 5824 min, sixth fault
ocd occurs at 6402 min, and seventh fault ocS at 6951 min, they are recorded as follows:
Drive Fault
Fault Record
Parameter
Fault Type
Fault Day
Parameter
Fault Minutes
Parameter
Fault Time
1st Fault P11�04 ovA P11�10 P11�11 3000
2nd Fault
P11�04 ovd P11�10 P11�11 3482
P11�05 ovA P11�12 P11�13 3000
3rd Fault
P11�04 ovA P11�10 P11�11 4051
P11�05 ovd P11�12 P11�13 3482
P11�06 ovA P11�14 P11�15 3000
5th Fault
P11�04 ocA P11�10 P11�11 5824
P11�05 ovA P11�12 P11�13 5003
P11�06 ovA P11�14 P11�15 4051
P11�07 ovd P11�16 P11�17 3482
P11�08 ovA n/a n/a n/a
6th Fault
P11�04 ocS P11�10 P11�11 6951
P11�05 ocA P11�12 P11�13 6402
P11�06 ocA P11�14 P11�15 5824
P11�07 ovA P11�16 P11�17 5003
P11�08 ovd n/a n/a n/a
P11�09 ovA n/a n/a n/a
Type Hex Addr Dec Addr
P11.18 Frequency Command at Fault
Read 0B12 42835
Range/Units (Format: 16-bit unsigned) Default
0�00~655�35 Hz
0
P11.18 shows the Frequency Command at the time of last drive fault. If another fault occurs, the
previous record will be overwritten.
Type Hex Addr Dec Addr
P11.19 Output Frequency at Fault
Read 0B13 42836
Range/Units (Format: 16-bit unsigned) Default
0�00~655�35 Hz
0
P11.19 shows the Output Frequency at the time of last drive fault. If another fault occurs, the
previous record will be overwritten.
Type Hex Addr Dec Addr
P11.20 Output Voltage at Fault
Read 0B14 42837
Range/Units (Format: 16-bit unsigned) Default
0�0~6553�5V
0
P11.20 shows the Output Voltage at the time of last drive fault. If another fault occurs, the
previous record will be overwritten.
Type Hex Addr Dec Addr
P11.21 DC Bus Voltage at Fault
Read 0B15 42838
Range/Units (Format: 16-bit unsigned) Default
0�0~6553�5V
0
P11.21 shows the DC Bus Voltage at the time of last drive fault. If another fault occurs, the
previous record will be overwritten.
