Automation Direct DURApulse GS4 User Manual

Chapter 5: Serial Communications
Page 5–3
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
GS4 Parameters Summary – Serial Communication Parameters (P9.xx) – (continued)
Parameter Range
Modbus Address Settings
Hex Dec Octal Default
P9.30
RS-485 Fault Reset
0: No Action
1: Fault Reset
091E 42335 4436 0
P9.31
RS-485 JOG Command
0: Stop
1: Jog
091F 42336 4437 0
P9.32
reserved n/a 0920 42337 4440 n/a
P9.33
GS4 Drive Rated Amps 0�00~655�34A 0921 42338 4441 #�##
P9.34
PLC Command Mask (status only) 0~65535 0922 42339 4442 0
P9.35
Response Delay Time 0�0~200�0 ms 0923 42340 4443 2�0
P9.36
reserved n/a 0924 42341 4444 n/a
P9.37
PLC Address 1~254 0925 42342 4445 2
P9.38
Firmware Date Code
Format: yywwd
• yy = year (2017 = 17)
• ww = week (1~52)
• d = day of week (1~7; Mon=1, Fri=5)
0926 42343 4446 #####
P9.39
Firmware version x�xx 0927 42344 4447 #�##
P9.40
reserved n/a 0928 42345 4450 n/a
P9.41
GS Series Number 0~9 0929 42346 4451 4
P9.42
GS Model ID
00: GS4-21P0 (230V 1ph/3ph 1�0hp)
01: GS4-22P0 (230V 1ph/3ph 2�0hp)
02: GS4-23P0 (230V 1ph/3ph 3�0hp)
03: GS4-25P0 (230V 3ph 5�0hp)
04: GS4-27P5 (230V 3ph 7�5hp)
05: GS4-2010 (230V 3ph 10hp)
06: GS4-2015 (230V 3ph 15hp)
07: GS4-2020 (230V 3ph 20hp)
08: GS4-2025 (230V 3ph 25hp)
09: GS4-2030 (230V 3ph 30hp)
10: GS4-2040 (230V 3ph 40hp)
11: GS4-2050 (230V 3ph 50hp)
12: GS4-2060 (230V 3ph 60hp)
13: GS4-2075 (230V 3ph 75hp)
14: GS4-2100 (230V 3ph 100hp)
15: GS4-41P0 (460V 3ph 1�0hp)
16: GS4-42P0 (460V 3ph 2�0hp)
17: GS4-43P0 (460V 3ph 3�0hp)
18: GS4-45P0 (460V 3ph 5�0hp)
19: GS4-47P5 (460V 3ph 7�5hp)
20: GS4-4010 (460V 3ph 10hp)
21: GS4-4015 (460V 3ph 15hp)
22: GS4-4020 (460V 3ph 20hp)
23: GS4-4025 (460V 3ph 25hp)
24: GS4-4030 (460V 3ph 30hp)
25: GS4-4040 (460V 3ph 40hp)
26: GS4-4050 (460V 3ph 50hp)
27: GS4-4060 (460V 3ph 60hp)
28: GS4-4075 (460V 3ph 75hp)
29: GS4-4100 (460V 3ph 100hp)
30: GS4-4125 (460V 3ph 125hp)
31: GS4-4150 (460V 3ph 150hp)
32: GS4-4175 (460V 3ph 175hp)
33: GS4-4200 (460V 3ph 200hp)
34: GS4-4250 (460V 3ph 250hp)
35: GS4-4300 (460V 3ph 300hp)
092A 42347 4452 ##
P9.43
Ignore Comm Card Warning
0: Disable function (do NOT ignore)
1: Enable function (ignore warning)
092B 42348 4453 1
(table continued next page)
